Kambic Air Baths & Temperature Controlled Chambers
Kambic air baths provide highly stable temperature-controlled environments for calibration laboratories, metrology, research and quality assurance applications.
Designed to deliver exceptional temperature uniformity and repeatability, these precision chambers are ideal for calibrating temperature sensors, probes and instrumentation where accuracy and stability are essential.
Available in a range of chamber sizes, Kambic air baths combine advanced temperature control with quiet operation and intuitive touchscreen controls.
- Highly stable temperature-controlled environments
- Designed for calibration and metrology applications
- Available in multiple chamber capacities
Exceptional Temperature Stability
Precision temperature control delivers outstanding stability and uniformity for calibration and testing applications.
Built for Metrology
Designed specifically for calibration laboratories requiring repeatable, traceable temperature performance.
User-Friendly Operation
Touchscreen controls and intuitive programming simplify everyday laboratory use.
Multiple Chamber Sizes
Available in capacities from compact laboratory units through to large calibration chambers.
Kambic air baths are designed for laboratories and organisations requiring accurate, ultra stable temperature environments for calibration and testing.
Typical applications include:
- Temperature sensor calibration
- RTD calibration
- Thermocouple calibration
- Metrology laboratories
- Calibration laboratories
- Instrument testing
- Research laboratories
- Quality assurance
- Industrial calibration
- Electronics testing
Their exceptional temperature stability makes them ideal wherever precise and repeatable thermal conditions are required.
- Stable temperature environment
- Excellent temperature uniformity
- Fan-forced air circulation
- Peltier-driven technology
- Quiet operation
- Touchscreen control panel
- LCD display
- Open-door alarm
- Stainless steel wire shelves
- Extensive thermal insulation
- Ethernet interface (optional)
- USB interface (optional)
- Additional shelves available
- Side access ports available
| Specification | TK-8 US | TK-50 US | TK-105 US | TK-190 US | TK-300 US |
|---|---|---|---|---|---|
| Volume | Approx. 8 L | Approx. 53 L | Approx. 105 L | Approx. 190 L | Approx. 300 L |
| Temperature range | +15°C to +50°C | +15°C to +50°C | +15°C to +50°C | +15°C to +50°C | +18°C to +35°C |
| Stability at 23°C | ±0.005°C | ±0.005°C | ±0.005°C | ±0.005°C | ±0.005°C |
| Uniformity at 23°C | ±0.01°C | ±0.01°C | ±0.01°C | ±0.02°C | ±0.04°C |
| External dimensions (W × H × D) | 230 × 578 × 332 mm | 705 × 865 × 640 mm | 705 × 1,130 × 700 mm | 875 × 1,300 × 700 mm | 905 × 1,490 × 800 mm |
| Internal dimensions (W × H × D) | 160 × 330 × 157 mm | 400 × 375 × 350 mm | 400 × 640 × 410 mm | 570 × 810 × 410 mm | 601 × 1,000 × 500 mm |
| Shelves | 2 | 2 | 2 | 2 | 2 |
| Weight | Approx. 25 kg | Approx. 79 kg | Approx. 112 kg | Approx. 150 kg | Approx. 210 kg |
Why Choose Kambic Air Baths?
Kambic air baths are engineered to provide highly stable and repeatable temperature-controlled environments for calibration laboratories, metrology facilities and research organisations.
Fan-forced air circulation, Peltier-driven temperature control and advanced insulation work together to deliver excellent chamber uniformity while maintaining quiet, energy-efficient operation.
Available in a range of chamber sizes from 8 L to 300 L, Kambic air baths can be matched to different calibration and testing requirements. With intuitive touchscreen controls, optional Ethernet and USB connectivity, and the technical support of Withnell Sensors, they provide a dependable solution for precision temperature calibration and laboratory testing.
DOWNLOAD
Download the Kambic Air Bath Brochure
Download the complete technical specifications, model comparison and product information for the Kambic air bath range.
Service & Maintenance
Preventative maintenance, equipment health checks and repair support for Haier Biomedical, FARRAR and Kambic equipment supplied by Withnell Sensors.
- Inspecting doors, handles, gaskets and seals
- Checking backup batteries and electrical components
- Inspecting pipework and testing for refrigerant leaks
- Removing ice and cleaning key components
- Completing operational and safety checks
