FARRAR ULT Chambers
[1 Models]FARRAR ULT Chambers provide large-capacity ultra-low temperature storage for pharmaceutical, biotechnology and life science applications.
Designed for operating temperatures from -20°C to -80°C, FARRAR’s forced-air convection technology delivers exceptional temperature uniformity, rapid recovery and up to six times the storage capacity of a conventional ultra-low temperature freezer.
Ideal for bulk storage of biological materials, drug products and process development, FARRAR ULT Chambers help maximise storage capacity while maintaining precise environmental control.
- Bulk ultra-low temperature storage from -20°C to -80°C
- Up to 6× the capacity of a standard ULT freezer
- Purpose-built for pharmaceutical and bioprocessing facilities
Bulk Cold Storage
Store up to 8,806 litres of valuable biological materials in a single ultra-low temperature chamber.
Forced-Air Convection
The only forced-air convection ultra-low temperature chamber operating between -20°C and -80°C, delivering fast recovery and consistent performance.
Exceptional Temperature Uniformity
Industry-leading temperature uniformity of ±3°C helps protect valuable products throughout the storage chamber.
Validation Ready
Available with IQ, OQ and PQ documentation to support GMP and regulated pharmaceutical environments.
FARRAR ULT Chambers are designed for organisations requiring reliable, high-capacity ultra-low temperature storage in regulated environments.
Typical applications include:
- Pharmaceutical manufacturing
- Drug substance storage
- Drug product storage
- Cell and gene therapy
- Bioprocessing
- Process development
- Biobanking
- Tissue banking
- Biological sample storage
- Long-term specimen preservation
The combination of bulk storage capacity, precise temperature control and forced-air convection technology makes FARRAR ULT Chambers ideal for facilities handling large volumes of temperature-sensitive materials.
FARRAR ULT Chambers combine large-capacity storage with precise temperature control and energy-efficient operation for demanding life science applications.
Key features include:
Two-year warranty
- Operating temperatures from -20°C to -80°C
- Forced-air convection cooling
- Precision temperature control (±1°C)
- Exceptional chamber uniformity (±3°C)
- Up to 8,806 L storage capacity
- Air- or water-cooled condenser options
- Integrated system redundancy
- Optimised storage footprint
- IQ/OQ/PQ validation available
| Specification | ULC | ULC-P |
|---|---|---|
| Chamber volume | 190 cu ft / 5,380 L | 311 cu ft / 8,806 L |
| Temperature range | -20°C to -80°C | -20°C to -80°C |
| Temperature control | ±1°C | ±1°C |
| Air-temperature uniformity | ±3°C, empty chamber | ±3°C, empty chamber |
| Evaporators | Two forced-air | Two forced-air |
| Condenser options | Forced-air-cooled or water-cooled | Forced-air-cooled or water-cooled |
| Air-cooled operating range | +18°C to +30°C | +18°C to +30°C |
| Water-cooled requirements | 29.5°C tower water; maximum 26.5 L/min | 29.5°C tower water; maximum 26.5 L/min |
| Area footprint | 47 sq ft / 4.36 m² | 67.5 sq ft / 6.28 m² |
| Interior dimensions (W × D × H) | 2,794 × 965 × 2,286 mm | 2,946 × 1,372 × 2,210 mm |
| Exterior dimensions (W × D × H) | 3,098 × 1,448 × 3,632 mm | 3,251 × 1,930.4 × 3,734 mm |
| Unit weight | 1,429 kg | 1,769 kg |
| Shipping weight | 1,769 kg | 2,132 kg |
Why Choose FARRAR ULT Chambers?
FARRAR ULT Chambers have been engineered specifically for pharmaceutical, biotechnology and life science organisations that require significantly greater storage capacity than traditional ultra-low temperature freezers.
By combining forced-air convection technology with exceptional temperature uniformity, they provide reliable bulk storage for valuable biological materials while supporting demanding GMP manufacturing and research environments.
Available in capacities of 5,380 L and 8,806 L, FARRAR ULT Chambers deliver up to six times the storage capacity of a conventional ULT freezer while reducing floor space requirements. With IQ/OQ/PQ validation support, precision temperature control and industry-leading chamber uniformity, they provide a scalable cold storage solution for organisations preparing for future growth.
DOWNLOAD
Download the FARRAR ULT Chamber Brochure
Download the full technical brochure, product specifications and performance information for the FARRAR ULT Chamber range.
Service & Maintenance
Preventative maintenance, equipment health checks and repair support for Haier Biomedical, FARRAR and Kambic equipment supplied by Withnell Sensors.
- Inspecting doors, handles, gaskets and seals
- Checking backup batteries and electrical components
- Inspecting pipework and testing for refrigerant leaks
- Removing ice and cleaning key components
- Completing operational and safety checks
Talk to a technical specialist
We are always on hand to offer expert and impartial advice and technical support.
